RL-SMHB6329
RL-SMHB6329 is a high bay light, available from 100W to 240W at 31,200 lumens at 130 lumens per watt. Colour temperature 3000K, 4000K, 5000K or 5700K. Available in cri>70, 420×420×67mm and 540×540×67mm sizes, rated IP65 for outdoor use. 0–10V, 1–10V or DALI dimming, runs on 100–277V, rated 50,000 hours. Typical uses: industrial and logistics.
3000K/4000K/5000K/5700KIP65
Specifications
- Power
- 100W / 150W / 200W / 240W
- Lumens
- 130lm/w / 13000lm / 19500lm / 26000lm / 31200lm
- CCT
- 3000K/4000K/5000K/5700K
- IP rating
- IP65
- Input voltage
- AC100~277V
- Power factor
- 0.98
- Dimming / driver
- 0-10V/1-10V/DALI
- Product size
- 420*420*67mm / 540*540*67mm
- LED Source
- SMD LED Chips
- Frequency Range
- 50~60Hz
- Color Rendering Index
- CRI>70
- Housing Color
- White
- Operation Temperature
- -30℃~+50℃
- Body & Shade Material
- Aluminum housing
- Working Life
- 50000 HOURS
- Warranty(Year)
- 5-Years
