- Beam angle
- 12° / 25° / 40° / 60°
- IP rating
- IP65/IP66
- Input voltage
- AC90‑305V/100‑277V
- Power factor
- >0.95
- Dimming / driver
- 0‑10V,1‑10V,DMX512,DALI,RGB/RGBW
- Warranty
- 5 Years
- Model
- RL‑HB5331
- Power Consumption(±5%)
- 400W (100%/80%/60% Tunable) / 500W (100%/80%/60% Tunable) / 600W (100%/80%/60% Tunable)
- Power Supply
- Inventronics/Moso/Sosen/Lifud
- Surge Protection
- 6KV
- Driver Type
- Constant Current (CC)
- LED Type
- Osram /Lumileds
- Light Efficacy(5000K, Ra70)
- 175Lm/W / 170Lm/W / 160Lm/W
- Luminous Flux (±10%)
- 70,000Lm / 85,000Lm / 96,000Lm
- Correlated Color Temperature
- 3000K, 4000K, 5000K, 5700K, 6500K
- Color Rendering Index
- 70, 80, 90, TLCI90 optional
- SDCM
- 6
- Product Dimension
- L378*W378*H199mm
(L14.88"W14.88"H7.83") / L378*W378*H185mm
(L14.88"W14.88"H7.28")
- Mounting Option
- Hoisting/ Ceiling installation/ Wall mounting
- Structure & Material & Finish
- Die‑casting Heat Sink/ ADC12 / Powder coated
Steel Metal Bracket / SPCC / Powder coated
- Lens
- PC Lens / PC Lens+Glass optional
- Fixture Color
- Black
- IK Rating
- IK08, IK10 optional
- Operating Temperature
- -40℃ ~ +70℃ (-40℉ - +158℉)
- Life Time of LED @Ta=25° C
- 50,000Hours
