LED High Bay Light · Catalogue P319-322

RL-HB5330

160-170Lm/W superior energy-saving solution

A versatile lighting fixture for various industrial, commercial, and indoor sports scenarios

17,000Lm/24,000Lm>70Ra/80RaIP65

Specifications

Lumens: 17,000Lm/24,000Lm
CCT: 3000K/4000K/5000K/5700K/6500K
CRI: >70Ra/80Ra
Beam angle: 60°/ 90°/ 120° (Three angles can be switched at will)
IP rating: IP65
Input voltage: AC220‑240V/AC100‑277V
Power factor: >0.9
Dimming / driver: 0‑10V/1‑10V/DALI
Warranty: 5 Years
Model: RL‑HB5330
Wattage Tunable: 100W (100%/80%/60% Tunable) / 150W (100%/80%/60% Tunable) / 200W (100%/80%/60% Tunable) / 240W (100%/80%/60% Tunable)
LED Type: Lumileds/Samsung
Efficiency: 160‑170Lm/W
Power Supply: Sosen/Lifud/Philips/Moso
Power Frequency: 50/60Hz
Output Voltage: DC180V‑260V
Power Efficiency: >93%
Total Harmonic Distortion: <15%
Ik code: IK10
Junction Temperature: <75℃(Ta=30℃)
Storage Temperature: -40℃——+70℃
Operating Temperature: -30℃——+45℃
Lifetime(L70 Standard): >50000Hrs(Ta=30℃)
Heat Radiator: Die‑cast aluminum
Lens Material: PC
