RL-RCHB6329

Specifications

Power

40W/50W/100W / 120W/150W / 200W

Lumens

120lm/w±5%

CCT

1800K 3000K 4000K 5000K 5700K 6500K

Beam angle

60°/90°/120°

Input voltage

AC100~277V

Dimming / driver

0-10V/1-10V/DALI

Hole cut

363*353mm / 405*395mm / 435*425mm

LED Source

Lumileds 3030

Frequency Range

50~60Hz

Total Harmonic Distortion

<20% (Typical : 10%)

Color Rendering Index

CRI>70/80

IP&IK Rating

IP67 IK10

Optical Transmittance

>97%

Housing Color

White

Working Environment

-30℃~+50℃, 10%~90% RH

Body & Shade Material

Aluminum housing & Annular lens

Working Life

50000 HOURS

Warranty(Year)

5-Year

Construction
