RL-EXP-WP264 20/30/40W
1. The shell is stretched and formed from high‑quality stainless‑steel plate. Its surface adopts high‑voltage electrostatic spraying for outstanding corrosion resistance.
2. The lampshade is made of heat‑resistant PC material.
3. Equipped with stainless‑steel mounting bracket and exposed stainless‑steel fasteners.
4. The light‑source cavity is structurally separated from the power‑supply and wiring cavities for easy installation and maintenance.
5. It adopts high‑efficiency, long‑lifespan, eco‑friendly SMD LED light source.
6. The LED light source and driver apply self‑developed core‑patented technology with encapsulated explosion‑proof design for enhanced safety and reliability.
7. It supports wide‑voltage input with constant‑current & constant‑voltage power supply and constant‑power output, featuring open‑circuit protection, short‑circuit protection and other protective functions.
Specifications
- Power
- 20/30/40W
- CCT
- 5500~6500K
- Input voltage
- AC 100‑277V 50HZ/60HZ DC18‑36V
- Power factor
- >0.9
- Dimming / driver
- 0‑10V/1‑10V/DALI
- Warranty
- 5 Years
- Model
- RL‑EXP‑WP264
- Lumen(lm)
- 2000/3000/4000lm
- Efficiency
- ≥100lm/W
- Ex‑mark
- ExebmbIICT5/6Gb ExtbIIICT80°C/T95°C
- Waterproof
- IP66
- Corrosion‑proof
- WF2
- Battery Emergency(E1) Battery Type(nickel‑chromium battery)
- Emergency power：4W±5% Emergency time：≥180min
- DC24V Emergency(E2)
- Emergency power：4W±5% Emergency voltage：DC18‑36V
- Temperature
- -35℃~+40℃/-35℃~+55℃
Dimensions
