Explosion Proof · Catalogue P305

RL-EXP-WP263

1. ATEX Marking: Ex II 2G Ex eb mb IIC T5 Gb / Ex II 2D Ex tb IIIC T100°C Db

2. Granted by French Design Award and Muse Design Award

3. IP66, IP69K, IK10 Approved; ATEX, IECEX, CE, RoHS Certified

4. Material: 3mm‑thickness S2000 Mitsubishi PC

5. End cap: PA66 + Fiberglass

6. Non‑flicker, THD＜15%, S304 ATEX cable gland, Anti‑UV

20W / 30W / 36W120°

Specifications

Power: 20W / 30W / 36W
Beam angle: 120°
Power factor: >0.95
Warranty: 5 Years
Model: RL‑EXP‑WP263
Lumen(lm): 3000 / 4500 / 5400
Light Source: SMD2835
CCT (Typ. K ± 10%): 3000K: 3045±175K, 4000K: 3985±275K, 5000K: 5029±283K, 6000K: 6065±415K
CRI (Ra): ≥80
Voltage‑Frequency: 100‑277V 50/60Hz
Waterproof: IP69K / IP66
IK Rate: IK10
Rated lifetime‑L80(hrs): 50000 hours
Operating temperature: −20 ~ +40℃
