LED Street Light · Catalogue P389-390

RL-SR2051-2

Series — RL-SR2051

High performance series street light providing ultra-flexible lighting solutions. The luminaire is specifically designed for long-lasting performance, made of high-pressure die-cast aluminum. It is designed with ZHAGA and NEMA sockets to provide numerous control options, available with 0-10V, DALI or custom dimming profiles

100W14000Lm / 140LM/WType II , Type III

Enquire about this product

Specifications

Power: 100W
Lumens: 14000Lm / 140LM/W
Beam angle: Type II , Type III
Input voltage: AC100-240V / 220-240V 50-60Hz
Power factor: >0.95
Dimming / driver: 0-10V, 1-10V, PWM, Timer dimming (Optional)
Material: High-pressure die-cast aluminum RAL9023 gray
Warranty: 5 Years
CCT (Typ. K ± 10%): 3000K, 4000K, 5700K
CRI (Ra): ≥70
SDCM: ≤6
Surge Protection: EDISON Isolated L-N: 4KV, MOSO:L-N: 5KV**, INVENTRONICS:L-N: 6KV
Lens: UV-resistant polycarbonate
Cover: Tempered glass
LED Drive: SG1 EDISON Isolated, SG2 MOSO (100-240V) INVENTRONICS (220-240V)
LED Brand/Model: EDISON 5050
Mounting: Side entry or post-top
Operating Temperature: -20 ~ +50℃
Storage humidity: 10% ~ 85%
Protection: IP66, IK09
Electrical class: CLASS II
Safety Approval: CB, CE, ENEC
Lumen maintenance: 50,000 hours at L70

Construction
