RL-SR2049-2
Series — RL-SR2049
High-performance street lighting solution independently developed by Edison. Featuring IK08-rated tempered glass and an IP66 waterproof rating, it ensures excellent durability and reliability. Compatible with smart control modules such as ZHAGA receptacles, it supports intelligent lighting functions including 0-10V dimming for versatile project applications
100W16500Lm / 165LM/W
Specifications
- Power
- 100W
- Lumens
- 16500Lm / 165LM/W
- Beam angle
- Type I, Type II , Type III, Type IV, Type V is optional
- Input voltage
- AC100-240V /220-240V 50-60Hz
- Power factor
- >0.95
- Dimming / driver
- 0-10V, 1-10V,PWM, Timer dimming (Optional)
- Material
- High-pressure die-cast aluminum , RAL9023 gray
- Warranty
- 5 Years
- CCT (Typ. K ± 10%)
- 1800K/ 2700K/ 3000K/3500K/4000K/5700K/6500K
- CRI (Ra)
- ≥70
- SDCM
- ≤6
- Surge Protection
- SPD 10KV/20KV is optional.
- Lens
- UV-resistant polycarbonate
- Cover
- Tempered glass
- LED Drive
- MOSO/INVENTRONICS/SOSEN
- LED Brand/Model
- EDISON 3030/5050
- Mounting
- Side entry or post-top
- Operating Temperature
- -20 ~ +50℃
- Storage humidity
- 10% ~ 85%
- Protection
- IP66, IK08
- Electrical class
- CLASS I or CLASS II
- Safety Approval
- CE
- Lumen maintenance
- 100,000 hours at L70
Construction
