LED Street Light · Catalogue P383-384

RL-SR2048

High performance series street light providing ultra-flexible lighting solutions. The luminaire is specifically designed with long-lasting performance, with high-pressure die-cast aluminum. It is designed with ZHAGA and NEMA sockets to provide numerous control options, available with 0-10V, DALI or custom dimming profiles

>70RaT2/T3/T4IP66

Enquire about this product Datasheet ↓

Specifications

Lumens: 5700LM-9600LM / 13300LM-19200LM / 24700LM-32000LM
CCT: 3000K/4000K/5000K/5700K/6500K
CRI: >70Ra
Beam angle: T2/T3/T4
IP rating: IP66
Input voltage: AC100-277V/220-240V
Power factor: 0.95
Dimming / driver: 0-10V/1-10V/DALI
Warranty: 5 Years
Model: RL-SR2048-30/40/50/60W / RL-SR2048-70/80/90/100/110/120W / RL-SR2048-130/140/150/160/170/180/190/200W
LED Type: Lumileds/Sanan
Efficiency: 160Lm/W-190Lm/W
Power Supply: Meanwell/Sosen/Inventronics
Power Frequency: 50/60Hz
Total Harmonic Distortion: <15%
SPD: Built-in 4KV, 10KV external SPD optional
Lifetime(L70 Standard): 50,000 hours
Heat Radiator: Die-cast aluminum
Lens Material: Glass

Construction
