- Power
- 3W / 1.5W / 1.5W (3W optional for underwater)
- Lumens
- / / 90‑95 lm / 60‑70 lm
- CCT
- RGB / 2700K, 3000K, 4000K, 6000K, R/G/B/A
- CRI
- / / 80+
- Beam angle
- 15°, 25°, 38°, 45°, 60°, 120° / 120° with milky white class
- IP rating
- IP68 Waterproof
- Input voltage
- DC12V / DC12V/DC24V
- Dimming / driver
- 0‑10V/1‑10V/DALI / Low voltage input, constant current output, excluding the transformer
- Material
- Stainless steel 316 / Solid Passivated (Anodizing) Aluminum CNC machined as standard. ( Stainless steel 316 as options) / Stainless steel 316 as standard, solid Passivated (Anodizing) Aluminum CNC machined as options / Solid Passivated (Anodizing) Aluminum CNC machined as standard, ( Stainless steel 316 as options)
- Warranty
- 5 years
- Item No.
- RL‑IG3901
- LED type
- 1PC 3030 RGB LED / 1 PC CREE XPE LED
- Certifications
- CE, RoHS
- Insulation class
- Class III
- Cable
- 1PC rubber cable 1M H05RN‑F 5x0.5mm square / 1PC rubber cable 1M H05RN‑F 2x1mm square
- IK rating
- IK06
- Protection finishing
- Stainless steel 316 / 20‑25μm thickness anodized film for Aluminum housing.
- Trim
- Stainless steel 316
- Glass
- Step tempered Glass. T=4mm. / Step tempered Glass painted in milky white. T=4mm.
- Cable Gland
- PG gland / PG7 IP68, Glue
- Gasket
- O‑ring PMQ silicone seal
- Mounting Sleeve
- Anti‑corrosion grey PVC tube (Convex type box as optoins)
