RL-IG1817
Outdoor installation, processed from high‑grade aluminum.Anti‑corrosive and UV‑resistant powder‑coated finish, 304 stainless‑steel cover.PC light panel.
100LM/W3000K/4000K/6500K>80IP65
Specifications
- Power
- 3W / 6W / 9W/12W / 18W / 24W / 36W / 48W
- Lumens
- 100LM/W
- CCT
- 3000K/4000K/6500K
- CRI
- >80
- IP rating
- IP65
- Input voltage
- 100‑240V
- Power factor
- 0.9
- Dimming / driver
- 0‑10V/1‑10V/DALI
- Product size
- φ100*H80mm / φ120*H100mm / φ150*H100mm / φ180*H100mm / φ200*H100mm / φ250*H100mm / φ320*H100mm
- Cut-out
- φ95*H80mm / φ115*H100mm / φ135*H100mm / φ158*H100mm / φ187*H100mm / φ240*H100mm / φ292*H100mm
- Material
- 304 stainless steel +aluminum+glass
- Colour
- stainless steel color
- LED chip
- SMD
- Lifetime
- 50000 hours
- Warranty
- 5 years
- Model
- RL‑IG1817
- Luminous angle
- 10° 30°45°60°
- Adjustable
- NO
