RL-WP236-NW
1.Sustainable Design
2.Efficiency up to 160LM/W
3.Easy Replacement of LED Board and Driver
4.DIP Power Switch and CCT Adjustable
5.Wiring Through upon Request
6.DALI, 1‑10V Dim, Motion Sensor, Emergency
80+120°
Specifications
- CRI
- 80+
- Beam angle
- 120°
- Input voltage
- 220~240Vac
- Power factor
- >0.95
- Dimming / driver
- 0‑10V/1‑10V/DALI / LIFUD
- LED chip
- LM80 Approval 2835
- Warranty
- 5 Years
- Model
- RL‑WP236‑NW
- Dimension (LxWxH)mm
- 665×76×72 / 1165×76×72 / 1465×76×72
- Power Consumption
- 20W / 40W / 60W
- Power Adjustable
- 10W‑13W‑15W‑20W / 22W‑28W‑34W‑40W / 34W‑42W‑51W‑60W
- LED Quantity (PCS)
- 144 / 304 / 464
- CCT Adjustable
- 3000K‑3500K‑4000K/3000K/4000K/6500K
- Luminaire Efficacy
- 140LM/W,160LM/W optional
- Working Temp
- -20℃~+45℃
- Waterproof rating
- IP65
Dimensions
