RL-WP236
1. Fast Wiring without opening the fixture
2. DALI, 1‑10V Dim, Motion Sensor, Emergency
3. Power Adjustable Optional
4. CCT Adjustable Optional
5. Wiring Through Upon Request
80+120°
Specifications
- Lumens
- 2800LM / 4200LM, 5600LM / 7000LM, 8400LM
- CRI
- 80+
- Beam angle
- 120°
- Input voltage
- 220~240Vac
- Power factor
- >0.95
- Dimming / driver
- 0‑10V/1‑10V/DALI / LIFUD/PHILIPS/OSRAM
- LED chip
- Epistar 2835
- Warranty
- 3‑5 Years
- Model
- RL‑WP236
- Dimension (LxWxH)
- 620*80*65MM / 1220*80*65MM / 1520*80*65MM
- Power Consumption
- 20W / 36/40/50W / 50/60W
- LED Quantity (PCS)
- 120 / 168,140 / 312,364
- CCT Adjustable
- 3000/4000/6500K
- Luminaire Efficacy
- 120‑140LM/W
- Working Temp
- -20℃~+45℃
- IP Rate & IK Rate
- IP65 & IK10
