RL-SQDL5503
The embedded anti-glare eye-protection downlight features a high-quality aluminum body that is die-cast in one piece, ensuring efficient heat dissipation and enhanced safety. available in black and white options.
100LM/W3000K/4000K/6500K/CCT>90120°
Specifications
- Power
- 7W / 12W / 15W / 18W / 24W / 30W
- Lumens
- 100LM/W
- CCT
- 3000K/4000K/6500K/CCT
- CRI
- >90
- Beam angle
- 120°
- IP rating
- IP65
- Input voltage
- 100-240V
- Power factor
- 0.5 / 0.95
- Dimming / driver
- 0-10V/1-10V/DALI / Included
- Product size
- 100*100*H45 / 120*120*H45 / 150*150*H45 / 175*175*H50 / 197*197*H50 / 230*230*H50
- Cut-out
- Ø75*75 / 90*90 / 120*120 / 140*140 / 160*160 / 190*190
- Material
- Aluminium / PC
- Colour
- White/ Black
- LED chip
- SMD
- Lifetime
- 50000 hours
- Warranty
- 5 Years
- Model
- RL-SQDL5503-SERIES
- Adjustable
- NO
- Diffuser
- PC
