RL-RECWW-01
RL-RECWW-01 is a wall washer, available from 6W to 24-36W at 100 lumens per watt. SMD LEDs in 3000K, 4000K or 6500K, CRI above 80. Aluminium, stainless steel, steel and glass body in stainless steel color, five sizes from 200×80×75 mm to 1000×90×75 mm, rated IP67 for wet areas. 0–10V, 1–10V, DALI or DMX512 dimming, runs on 100–240V, rated 30,000 hours, and a three-year warranty. Typical uses: public realm and urban; worship & culture.
100LM/W3000K/4000K/6500K>80IP67
Specifications
- Power
- 6W / 9-12W / 12-18W / 18-24W / 24-36W
- Lumens
- 100LM/W
- CCT
- 3000K/4000K/6500K
- CRI
- >80
- IP rating
- IP67
- Input voltage
- 100-240V
- Power factor
- 0.5
- Dimming / driver
- 0-10V/1-10V/DALI/DMX512
- Product size
- L200*W80*H75 / L300*W90*H75 / L500*W90*H75 / L600*W90*H75 / L1000*W90*H75
- Cut-out
- L190*75*H80 / L285*75*H80 / L485*75*H80 / L585*75*H80 / L985*75*H80
- Material
- 304 stainless steel +aluminum+glass
- Colour
- stainless steel color
- LED chip
- SMD
- Lifetime
- 30000 hours
- Warranty
- 3 years
- Item No.
- RL-RECWW-01
- Luminous angle
- 10° 30°45°60°
- Adjustable
- NO
