RL-FD-MESH
1. Lampshade: Transparent face mask, emitting light at 120 degrees
2. Easy to install: compact in size, standardized, easy to install and maintain
3. Standardization: Standard male and female plug‑in foolproof wiring, standardized components, waterproof and foolproof, easy to operate and maintain
4. High protection: The protection level is IP67, and not only does it adopt the back‑sealing process, but it also applies ultrasonic welding technology
5. High reliability: UV resistant, flame‑retardant V‑0, working life of 50000 hours
6. Trimmable: Cut the appropriate grid‑screen length according to the building's exterior requirements
7. Control: breakpoint continuation control, high fault tolerance
0.7W / 1W / 1.3WIP67
Specifications
- Power
- 0.7W / 1W / 1.3W
- Lumens
- 10.25LM / 15.5LM / 28.02LM / 39.7LM
- IP rating
- IP67
- Dimming / driver
- 110° / 120° / 0/1‑10V/DALI/DMX512
- Warranty
- 5 Years
- Model
- RL‑FD‑MESH‑2 / RL‑FD‑MESH‑4 / RL‑FD‑MESH‑6 / RL‑FD‑MESH‑H
- Rated working
- DC12V / DC24V / DC36V
- Control mode
- Break point resume
- Grey scale
- 65536
- Pixel segment
- 1
- LED Qty
- 3535RGB*2 / 2727RGB*4 / 2727RGB*6 / 5054RGB*1
- Luminous
- 3.8
- LED Efficacy
- 14.7LM/W / 15.5LM/W / 21.5LM/W / 31.5LM/W
- LED Beam
- EDISON Isolated L‑N: 4KV, MOSO:L‑N: 5KV**,INVENTRONICS:L‑N: 6KV
- Lead wire
- 2*0.75mm2+2*0.3mm2
- Electrical
- Class Ⅲ
- Flammability
- 94‑V0
- Type of cover
- Transparent face mask
- Cover
- PC
- Shell color
- Black/grey
- Body
- PC
- Oper Temp
- -20~60°C
- Storage
- -40~75°C
- Safety Approval
- CB, CE, ENEC
- Lumen maintenance
- 50,000 hours
- Installation
- Steel wire installation
Construction
