RL-EXP-WP262
1. Patent‑designed for explosion‑proof protection performance. Aluminum‑alloy body to maximize optimal heat transmission.
2. PC cover with excellent anti‑corrosion performance, shock‑resistant and vibration‑resistant, anti‑glare, light transmittance＞90%.
3. Perfect replacement for the shape of traditional explosion‑proof fluorescent lamps.
4. LED: LM80‑certified, 120‑140 lm/W, luminous flux up to 14000 lumen.
5. High‑efficiency LED driver with a lifespan of over 50000 hours.
6. Circuit design: 4KV/6KV surge‑protection power supply.
7. Protection: IP66 high‑protection grade for waterproof and dust‑proof performance.
120‑140Lm /w120°
Specifications
- Power
- 20/30W / 20/30/40/50W / 40/50/60/70W / 40/50/60/70/80/100W
- Lumens
- 120‑140Lm /w
- Beam angle
- 120°
- Power factor
- >0.95
- Dimming / driver
- 0‑10V/1‑10V/DALI
- Product size
- 329*125*168.7 / 629*125*168.7 / 929*125*168.7 / 1229*125*168.7
- Warranty
- 5 Years
- Model
- RL‑EXP‑WP262‑A / RL‑EXP‑WP262‑B / RL‑EXP‑WP262‑C / RL‑EXP‑WP262‑D
- CCT (Typ. K ± 10%)
- 3000‑6500K
- CRI (Ra)
- ≥70
- Voltage‑Frequency
- 12‑24V DC/100‑277 Vac 50‑60Hz
- Power supply
- High efficiency LED driver, more than 50000 hours lifespan
- Rated lifetime‑L70(hrs)
- 50000 hours
- THD
- <10%
- Operating temperature
- −40 ~ +50℃
- Entry size
- 3/4"‑14 NPT or M25*1.5 or M26*1.5
- Cable
- Three‑core rubber cable, ICE(CE)certification,with 0.5m cable(Standard)
Construction
