RL-DL1604
Deep cup antiglare design, available in black and white cups,The white cup provides a brighter visual effect,And the black light cup absorbs a large amount of stray light,
Provide better anti glare performance(The brightness decreases by about 5%).
15W / 20W / 25W / 35W100LM/W3000K/4000K/6500K/CCT>90
Specifications
- Power
- 15W / 20W / 25W / 35W
- Lumens
- 100LM/W
- CCT
- 3000K/4000K/6500K/CCT
- CRI
- >90
- Beam angle
- 20° 40° 60°
- IP rating
- IP44
- Input voltage
- 100-240V
- Power factor
- 0.5 / 0.95
- Dimming / driver
- 0-10V/1-10V/DALI / Included
- Product size
- Ø105*70 / Ø131*75 / Ø160*80 / Ø182*90
- Cut-out
- Ø95 / Ø105 / Ø145 / Ø165
- Material
- Aluminium / PC
- Colour
- White/Black
- LED chip
- COB
- Lifetime
- 50000 hours
- Warranty
- 5 Years
- Model
- RL-DL1604 SERIES
- Adjustable
- NO
- Diffuser
- PC
