RL-DL1603
High power anti glare tube light with deep cupembedded designThickened aluminum integral forged plate radiator,Efficient heat dissipation, effectively extending service life.
100LM/W3000K/4000K/6500K/CCT>9024° 36° 60°
Specifications
- Power
- 7-10W / 12-18W / 20-25W / 30-35W / 40-45W / 50-55W
- Lumens
- 100LM/W
- CCT
- 3000K/4000K/6500K/CCT
- CRI
- >90
- Beam angle
- 24° 36° 60°
- IP rating
- IP44
- Input voltage
- 100-240V
- Power factor
- 0.5 / 0.95
- Dimming / driver
- 0-10V/1-10V/DALI / Included
- Product size
- Ø85*H49.5 / Ø110*H67 / Ø135*H81 / Ø160*H96 / Ø185*H109 / Ø215*H130
- Cut-out
- Ø75 / Ø95 / Ø120 / Ø140 / Ø160 / Ø190
- Material
- Aluminium / PC
- Colour
- White/Black
- LED chip
- COB
- Lifetime
- 50000 hours
- Warranty
- 5 Years
- Model
- RL-DL1603 SERIES
- Adjustable
- NO
- Diffuser
- PC
